| Practical Sound Absorption Coefficient (αp) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Edge | Thickness | Suspension height | 125Hz | 250Hz | 500Hz | 1000Hz | 2000Hz | 4000Hz | Sound absorption class | αw | NRC |
| A24, A15, E15, E24 | 12mm | 200mm | 0,40 | 0,80 | 0,85 | 0,75 | 0,80 | 0,80 | B | 0,80 | 0,80 |
Sound absorption is measured in accordance with ISO 354.
Sound absorption data αp, αw and absorption class are calculated in accordance with ISO 11654. Sound absorption properties of islands and baffles are quantified by the equivalent sound absorption area Aeq expressed as m² per item.
| Reaction To Fire | A1 (EN 13501-1) | |
|---|---|---|---|
|
Reaction to fire is classified in accordance with EN 13501-1.
| |||
| Humidity And Sag Resistance | Up to 100% RH. No visible deflection in high humidity. There will always be some dust/dirt on the panels after some time, and with regular exposure to high humidity this could lead to fungi growth. Please avoid condensation on the panel | |
|
ROCKFON ceiling tiles are dimensionally stable even at humidity levels of up to 100% relative humidity and can be installed at all temperatures ranging from 0°C to 40°C. They can be installed during the very early stage of the build (when windows are not fully sealed). Their lightweight yet stable non-hygroscopic character minimises the final weight of the fully-installed ceiling. ROCKFON ceiling tiles are predominantly classified as Class 1/C/0N in accordance with EN 13964. Certain module sizes (width above 700mm) are Class 2/C/0N.
| |||
| Cleaning | Vacuum | |
|
| |||
| Hygiene | Stone wool provides no sustenance to microorganisms | |
|
Stone wool provides no sustenance to the following microorganisms tested in accordance with JIS Z 2801:2000 and ASTM C 1338-96: – Escherichia coli – Staphylococcus aureus – Methicillin-resistant staphylococcus aureus (MRSA) – Stachybotrys chartarum – Penicillium brevicumpactum – Alternaria tenuissima – Aspergillus niger – Sporobolomyces roseum – Rhodotorula rubra
| |||
| Environment | Fully recyclable stone wool | |
|
| |||
| Indoor Environment | A selection of Rockfon products have been awarded the Finnish M1 emission classification for building materials and the Danish Indoor Climate Label for low emission products | |
|
| |||
| Edge | Dimensions (mm) | Thickness (mm) | Weight (Kg/m2) | Min. suspension height (mm) | Recommended installation system | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A15 |
| 1200 x 600 | 12 | 1,60 | 0 | |||||||||||||||||||
Sound absorption details
Tile details
Packaging
| ||||||||||||||||||||||||
| A15 |
| 600 x 600 | 12 | 1,60 | 0 | |||||||||||||||||||
Sound absorption details
Tile details
Packaging
| ||||||||||||||||||||||||
| A24 |
| 1200 x 600 | 12 | 1,60 | 0 | |||||||||||||||||||
Sound absorption details
Tile details
Packaging
| ||||||||||||||||||||||||
| A24 |
| 600 x 600 | 12 | 1,60 | 0 | |||||||||||||||||||
Sound absorption details
Tile details
Packaging
| ||||||||||||||||||||||||
| E15 |
| 600 x 600 | 12 | 1,90 | 0 | |||||||||||||||||||
Sound absorption details
Tile details
Packaging
| ||||||||||||||||||||||||
| E24 |
| 600 x 600 | 12 | 1,90 | 0 | |||||||||||||||||||
Sound absorption details
Tile details
Packaging
| ||||||||||||||||||||||||
| Sound curve |
| |
|---|---|---|
| Minimum installation height | 0 mm |
|---|---|
| Easy access | - |
| Pieces Per Pack | 20 |
|---|---|
| Area Per Pack | 14,4 m2 |
| Sound curve |
| |
|---|---|---|
| Minimum installation height | 0 mm |
|---|---|
| Easy access | - |
| Pieces Per Pack | 40 |
|---|---|
| Area Per Pack | 14,4 m2 |
| Sound curve |
| |
|---|---|---|
| Minimum installation height | 0 mm |
|---|---|
| Easy access | - |
| Pieces Per Pack | 20 |
|---|---|
| Area Per Pack | 14,4 m2 |
| Sound curve |
| |
|---|---|---|
| Minimum installation height | 0 mm |
|---|---|
| Easy access | - |
| Pieces Per Pack | 40 |
|---|---|
| Area Per Pack | 14,4 m2 |
| Sound curve |
| |
|---|---|---|
| Minimum installation height | 0 mm |
|---|---|
| Easy access | - |
| Pieces Per Pack | 20 |
|---|---|
| Area Per Pack | 7,2 m2 |
| Sound curve |
| |
|---|---|---|
| Minimum installation height | 0 mm |
|---|---|
| Easy access | - |
| Pieces Per Pack | 20 |
|---|---|
| Area Per Pack | 7,2 m2 |
